| Series | FJN08K |
| Package diameter | 20mm |
| Operating Direction | Horizontal Vertical |
| Bushing material | |
| Number of Gangs | N/A |
| Power-linear | 0.0125W |
| Power-audio | N/A |
| Life cycle | 1 Million cycles |
| Switch Option | N/A |
| Detent Option | N/A |
| Mounting | |
| Element | 2 gangs |
| Temperature ppm/℃ | |
| Tolerance | |
| Pulse | |
| Shaft material | Plastic |
| Life cycle | |
| Operating type | |
| Power rating | |
| Travel(mm) | |
| Lever length | |
| Turns | |
| Specification | Document download |
Introdution
1.Superior operational feeling free from gaps in operating directions Ideal for finger-tip operation.
2.Integrated tact switch for selection contributes to the improvement of user-friendliness of the set.
| Electrical characteristics | |
| Total Resistance | 10KΩ |
| Total Resistance Tolerance | ± 20% |
| Resistance Taper | B taper |
| Rated Power | Taper B: 0.0125W |
| Withstand Voltage | 1 minute at AC 250V |
| Insulation Resistance | More than 100MΩat DC 250V |
| Contact Resistance | Less than 20% of the total resistance |
| Mechanical characteristics | |
| Figure of the Slide Bar Operating | Slide on the 2D flat |
| Stopper Strength of the Slide Bar | More than 3.0Kgf for 3Sec. Min |
| Pull Strength of Slide Bar | More than 3.0Kgf for 3Sec. Min |
| Push Strength of Slide Bar | More than 3.0Kgf for 3Sec. Min |
| Travel of the Slide Bar | 2mm |
| Operating Force of Slide Bar | 60±20gf |
| Durability | |
| Rotational Life | 1,000,000 Cycles Min |
