| Series | FJR06K |
| Package diameter | 11 |
| Operating Direction | Horizontal |
| Bushing material | |
| Number of Gangs | |
| Power-linear | |
| Power-audio | |
| Life cycle | 1 million cycles |
| Switch Option | Y |
| Detent Option | |
| Mounting | |
| Element | |
| Temperature ppm/℃ | |
| Tolerance | |
| Pulse | |
| Shaft material | Metal |
| Life cycle | |
| Operating type | |
| Power rating | |
| Travel(mm) | |
| Lever length | |
| Turns | |
| Specification | Document download |
Introdution
1. Miniature dimensions of 11mm * 11mm * 6mm
2. Switch function available
3. Perfect for portable gaming devices
| Electrical characteristics | |
| Total Resistance | 10KΩ |
| Total Resistance Tolerance | ± 20% |
| Resistance Taper | B taper |
| Rated Power | Taper B: 0.0125W |
| Withstand Voltage | 1 minute at AC 250V |
| Insulation Resistance | More than 100MΩat DC 250V for 1 minute |
| Max. Operating Voltage | Taper B: AC 50V or DC 5.0V |
| Noise | Less than 300mV |
| Voltage Dicider Error | 38%~62% |
| Mechanical characteristics | |
| Figure of lever operation | Circular Operating |
| Stopper Strength | 3.0Kgf.cm Min 3Sec. |
| Operating angle of lever | 50°MAX |
| Push-Pull Strength | Push/Pull: 5.0Kgf Min 3Sec. |
| Operating Force | 140±50gf.cm |
| Accuracy of rest position | ±5° |
| Durability | |
| Rotational Life | 1Million Cycles Min. |
| Operating Temperature Range | -30°~+80° |
| Tact Switch specification | |
| Ratings | 5 V DC, 5mA |
| Operating Force | 750±150gf.cm |
| Travel | 0.35+0.25/-0.1mm |
| Operating life | 200,000 Cycles min |
