| Series | F10KV |
| Package diameter | 10mm |
| Operating Direction | Horizontal Vertical |
| Bushing material | |
| Number of Gangs | N/A |
| Power-linear | 0.0125W |
| Power-audio | 0.0125W |
| Life cycle | 1Million cycles |
| Switch Option | N/A |
| Detent Option | N/A |
| Mounting | |
| Element | 1 piece |
| Temperature ppm/℃ | |
| Tolerance | |
| Pulse | |
| Shaft material | Plastic |
| Life cycle | |
| Operating type | |
| Power rating | |
| Travel(mm) | |
| Lever length | |
| Turns | |
| Specification | Document download |
Introdution
1.Carbon element.
2.Inserting molding around the resistor with resin.
3.Long life, Miniature structure .
| Electrical characteristics | |
| Total Resistance | 1KΩ -1MΩ |
| Total Resistance Tolerance | 500Ω |
| Resistance Taper | B |
| Rated Power | 0.0125W |
| Withstand Voltage | 1 minute at AC 250V |
| Insulation Resistance | More than 100MΩ at DC 250V 1 Minute |
| Max. Operating Voltage | AC50V.DC 5V |
| Residual Resistance | Term.1~2: Less than 5% of Total Resistance: Term.2~3: Less than 5% of Total Resistance |
| Rotational Noise | Less than 300mV |
| Mechanical characteristics | |
| Total Rotational Angle | 300°±10° |
| Rotational Torque | 3~50gf.cm |
| Rotational Stopper Strength | 2Kgf.cm Min. |
| Push-Pull Strength | Push: 5Kgf Min: Pull: 5Kgf Min |
| Durability | |
| Rotational Life | Standard life: 100,000 Cycles Min.: Long life: 1Million Cycles Min. |
